1
2
3
4
5
1

The rim

9 rim shapes available

2

The cup

22 cup diameters and
6 different depths

3

The backbore

7 different backbores for trumpet

4

The throat

11 different throats, from 3,50 mm up to 4,50 mm

5

The materials

The use of high quality raw materials gives the product a great sound quality.

Mouthpiece Care and Maintenance

We recommend handling and cleaning the mouthpiece with particular care, as its precious metal coating,
24K gold or 999 fine silver, is delicate and requires special attention. Avoid abrasive products,
harsh chemicals, and excessive rubbing to preserve the shine and beauty of your Frate Precision mouthpiece over time.

Thanks to the most recent technologies based on CAD-CAM software planning during the productive process and to the product making with CNC machines,
we are able to guarantee any mouthpiece can be reproduced with centesimal tolerances.

The Cup for Trumpet, Flugelhorn, Piccolo Trumpet and Cornet ——– (numbers from 1+ to 6+) ——– (numbers from 1 to 12)

Number from 1+  to  6+
Wide cup diameter

N. 1+    cup diameter  17.66  mm
N. 2+    cup diameter  17.48  mm   *
N. 3+    cup diameter  17.30  mm
N. 4+    cup diameter  17.30  mm   *
N. 5+    cup diameter  17.12  mm
N. 6+    cup diameter  17.12  mm   *

(* V shape of the cup)

Number from 1  to  12
Cup diameter

N. 1     cup diameter  16.95 mm
N. 2     cup diameter  16.95 mm   *
N. 3     cup diameter  16.62 mm
N. 4     cup diameter  16.62 mm   *
N. 5     cup diameter  16.35 mm
N. 6     cup diameter  16.28 mm   *

.
.

N. 7       cup diameter  16.22 mm
N. 8       cup diameter  16.08 mm
N. 9       cup diameter  16.08 mm   *
N. 10     cup diameter  15.88 mm
N. 11     cup diameter  15.88 mm   *
N. 12     cup diameter  15.60 mm

FIRST LETTER
Depth of the cup

Letter  L      Lead – Extra Shallow
Letter  S      Shallow
Letter  H     High cup
Letter  M    Medium deep
Letter  D     Deep
Letter  X     eXtra deep

SECOND LETTER
Rim shape (Trumpet, Flugelhorn, Piccolo Trumpet and Cornet)

no letter engraved

rim standard
external diameter  27.26 mm

             letter  S

Semi-rounded rim
external diameter  27.43 mm

letter  M

Medium rim
external diameter  27.43 mm

letter  R

Rounded rim
external diameter  27.58 mm

letter  N

Narrow rim well rounded
external diameter  27.05 mm

letter  F

Flat rim
external diameter  27.30 mm

letter  L

Large semi-rounded rim
external diameter  27.60 mm

letter  W

Wide rounded rim
external diameter  27.80 mm

letter  X

eXtra-wide semi-rounded rim
external diameter  29.20 mm

The Cup for Natural Trumpet ——– (numbers from 1 to 7)

Number from 1  to  7
Cup diameter

N. 1     cup diameter  17.48 mm
N. 2     cup diameter  17.30 mm
N. 3     cup diameter  17.12 mm
N. 4     cup diameter  16.95 mm


Cup diameter

N. 5     cup diameter  16.62 mm
N. 6     cup diameter  16.35 mm
N. 7     cup diameter  16.22 mm

FIRST LETTER
Depth of the cup

Letter  H     High cup
Letter  M    Medium deep
Letter  D     Deep

The cup for French Horn ——– (numbers from 1 to 16)

N. 1      cup diameter  18.48  mm
N. 1+    cup diameter  18.30  mm
N. 2      cup diameter  18.48  mm
N. 2+    cup diameter  18.30  mm
N. 3      cup diameter  18.12  mm
N. 3+    cup diameter  17.82  mm
N. 4      cup diameter  18.12  mm
N. 4+    cup diameter  17.82  mm
N. 5      cup diameter  17.52  mm
N. 6      cup diameter  17.52  mm

N.  7     cup diameter  17.30  mm
N.  8     cup diameter  17.30  mm
N.  9     cup diameter  16.95  mm
N. 10    cup diameter  16.95  mm
N. 11    cup diameter  16.62  mm
N. 12    cup diameter  16.62  mm
N. 13    cup diameter  16.22  mm
N. 14    cup diameter  16.22  mm
N. 15    cup diameter  15.88  mm
N. 16    cup diameter  15.88  mm

FIRST LETTER
Depth of the cup

Letter  H     High cup
Letter  M    Medium deep
Letter  D     Deep

SECOND LETTER
Rim shape (French Horn)

no letter engraved

rounded rim standard
thickness 3,82 mm

             letter  S

Semi-rounded rim
thickness 4,05 mm

letter  F

Flat rim
thickness 3,82 mm

letter  L

Large rim semi-rounded
thickness 4,30 mm

The Throat

Throat numberDiameterDescription
no. 0
3.50 mm
no. 13.58 mm
no. 2 (Standard for Trumpet and Piccolo Trumpet)3.66 mmThroat n. 2 not engraved on Trumpet and P. Trumpet
no. 33.74 mmSuggested with medium large backbore
no. 43.82 mm Suggested for C trumpet and rotary trumpet
no. 53.90 mm
no. 63.98 mm
no. 7 (Standard for Flugelhorn and Cornet)4.06 mm Throat n. 7 not engraved on Flugelhorn and Cornet
no. 84.14 mm
no. 94.30 mm Special for French Horn mouthpiece
nr. 104.50 mmStandard for French Horn mouthpiece

The Backbore and the Shank

CLASSIFICATION OF THE BACKBORE FOR TRUMPET DESCRIPTION
LARGE no. 110
Available only for Trumpet standard shank		Roman number CX engraved on the shank
Very open shape, huge and unic sound
MEDIUM-LARGE no.106
Backbore standard in combination with throat n. 3-4-5-6		Roman number CVI engraved on the shank
Full, rich, and open sound
MEDIUM- LARGE no. 105Roman number CV engraved on the shank
Warm and homogeneous sound
MEDIUM- LARGE no. 102Roman number CII engraved on the shank
Open and resonant sound. Slightly less open than #105 and #106 backbores
MEDIUM no. 101
Backbore standard in combination with throat n. 0-1-2		Standard backbore code not engraved
Bright sound
SEMI-NARROW no. 104Roman number CIV engraved on the shank
Bright and resonant sound
NARROW no. 103
Available only for Trumpet standard shank
Roman number CIII engraved on the shank
Bright and edgy sound
CLASSIFICATION OF THE SHANKDESCRIPTION
standard Trumpet shank for Bb and C TRUMPETshank code not engraved – lenght of the mouthpiece 87,5 mm
Medium Trumpet shank for Bb and C TRUMPETM engraved on the shank – lenght of the mouthpiece 80 mm
Short Trumpet shank for Eb TRUMPET and PICCOLO TRUMPETS engraved on the shank – lenght of the mouthpiece 74,5 mm
PICCOLO TRUMPET Cornet shankP engraved on the shank
FLUGELHORN Small shankF engraved on the shank
FLUGELHORN Large shankFL engraved on the shank
CORNET Standard shankCO engraved on the shank
CORNET Short shankshank code not engraved
